Induction Heating Steam  Generator

Induction Heating Steam Generator

ZG-EH-SG Series Electromagnetic Induction Heating Steam Generator
ZG-EH-SG Series Electromagnetic Induction Heating Steam Generator
ZG-EH-SG Series Electromagnetic Induction Heating Steam Generator
ZG-EH-SG Series Electromagnetic Induction Heating Steam Generator

ZG-EH-SG Series Electromagnetic Induction Heating Steam Generator

Descriptions

Model No.: ZG-EH3.5-SG, ZG-EH05-SG, ZG-EH06-SG, ZG-EH08-SG, ZG-EH12-SG, ZG-EH16-SG, ZG-EH30-SG, ZG-EH60-SG.

Rated Power: 3.5kw, 5kw, 6kw, 8kw, 12kw, 16kw, 30kw, 60kw

Main Function: heating water to high temperature over 120C degrees and quickly generating steam out.

Main Advantage: Electromagnetic Induction heating steam generator can save at least 30%~50% electricity than resistance wire heating, generating steam very fast within 60S.

Inquire Now
Share:
APPLICATION

1, Steam cleaning industry;

2, Sauna bathing in the leisure beauty clubs;

3, Hot water supply for the hotels, schools, hospitals;

4, Concrete maintenance for bridges & railways;

5, Rolling ball machine and setting machine in plush industry;

6, Food machinery industry like steam box, sealing machine, packing machine and so on;

7, Biochemical Industry: fermentation tank, reaction kettle, emulsifier etc;

8, Clothing washing industry: dryer, dry cleaner;

9, Automotive washing industry and other industries.


ZG-EH-SG Series Electromagnetic Induction Heating Steam Generator

MAIN FEATURES

Electromagnetic Induction Heating Steam Generator is using energy saving High-frequency induction heating converting heat energy in a very efficient way and the thermal efficiency can save up to 30%~70% than the traditionaresistance wire heating;

The heating element of Electromagnetic Induction Heating Steam Generator does not need maintenance charges because the heating element will not get high temperature and no cause of burning, which is unlike the traditional heaters that have resistance wire heating and the wires inside easily get burned.

The used steam would become waste water, which can be circling used and the temperature of the waste water is high and easily recycled and heated into steam again, so the energy saving will be saved in this way too;

No requirements of water quality: we can use normal tap water for heating

Rapid heating speed: steam will come out in 60s.

No pollution at all. Production.

No electricity in water and totally safe for human: the Electromagnetic Induction Heating Steam Generator has a built-in steam-water isolation system.


ZG-EH-SG Series Electromagnetic Induction Heating Steam Generator

TECHNICAL PARAMETER
Item No.Rated PowerInputVoltageHeating CurrentSteamTemp.Steam PressureSteam VolumeHeat Exchange RateSteam Outlet PipeSafety Value PipeWater Inlet PipeSewage PipeDimension(L*W*H)
UnitKWVAMPAKGS/H%mmmmmmmmMm3
ZG-EH3.5SG3.5220V-1P50HZ161650.7598%DN8DN15DN4DN15440*420*320
ZG-EH05SG5220V-1P50HZ22A1650.71298%DN8DN15DN4DN15440*420*320
ZG-EH08-SG8220V-1P50HZ36A1650.71298%DN15DN20DN15DN15480*500*520
ZG-EH12-SG12380V-3P50HZ18A1650.71798%DN15DN20DN15DN15480*500*520
ZG-EH16-SG16380V-3P50HZ22A1650.72298%DN15DN20DN15DN15480*500*520
ZG-EH30-SG30380V-3P50Hz45A1650.74098%DN15DN20DN15DN15510*1230*820
ZG-EH60-SG60380V-3P50Hz90A1650.78598%DN15DN20DN15DN15560*1280*822


ZG-EH-SG Series Electromagnetic Induction Heating Steam Generator
